Product Details:
Payment & Shipping Terms:
|
Name: | Stainless Steel Window Screen | Screen Netting Material: | Stainless Steel,Fiberglass,aluminium |
---|---|---|---|
Type: | Door & Window Screens,Linear | Color: | White,blackdark Gray Light Gray |
Width: | 750mm,0.5-2m,900mm,1200mm,0.6m | Mesh: | Etc,14x14,11*11,16X16,10-30 |
Material: | Stainless Steel Wire,316,Fiberglass,galvanized Iron Wire,Nylon | Application: | Anti Insect,Sliding Windows,Protecting Mesh,Residential,insect Screen |
Length: | 30m,2400mm,50m Or As Customer Require,1500mm,1-30m | Mesh Size: | 11x11mesh,Customers's Requirement,22X22 30x30,0.8mm(11x11) 0.7mm(12x12),etc |
Feature: | Good Ventilation,Corrosion Resistance,light Weight,good Toughness,Easy Install | Surface Treatment: | Electrostatic Powder Spraying,Natural,metal,Epoxy Resin Paint,powder Coating |
Wire Diameter: | 0.8mm,0.7mm-1.0mm,0.08mm To 0.5mm,BWG34 Etc,0.08~0.3mm/ As Your Requirment | Packing: | Water Proof Plastic Bags Outside,With Paper Tube Inside,carton,waterproof Paper,as Request |
Weave Type: | Plain Weave,Plain Weave And Inter Weave,Plain Woven | Weight: | 110g-120g/m2,110g 120g,100-150g /sqm,20-150g/m2 |
Size: | 900x2400mm,Normal Size(like 100*100cm) Or Custom,1.2m*2m,Customized Size | Advantage: | Competitive Price,anti-rats,unity-structure,anti-theft,anti-flies |
High Light: | SUS201 stainless steel fly mesh,5ft stainless steel fly mesh,Dutch Weave 5ft Wire Mesh |
Material of stainless steel wire mesh
SUS201,SUS304,SUS304L,SUS316,SUS316L
Weaving method of stainless steel wire mesh
Plain weave,twilled weave,dutch weave.
Uses of stainless steel wire mesh
Extensively used in mining,chemial industury,food industury and pharamaceutial industury.
Characteristics of stainless steel wire mesh
Acid reistance ,Alkali resistance,heat resistance,corrosion resistance
mesh/inch | wire diameter/mm | aperture/mm | mesh/inch | wire diameter/mm | aperture/mm |
2mesh | 1.8 | 10.9 | 60mesh | 0.15 | 0.273 |
3mesh | 1.6 | 6.866 | 70mesh | 0.14 | 0.223 |
4mesh | 1.2 | 5.15 | 80mesh | 0.12 | 0.198 |
5mesh | 0.91 | 4.17 | 90mesh | 0.11 | 0.172 |
6mesh | 0.81 | 3.433 | 100mesh | 0.1 | 0.154 |
8mesh | 0.6 | 2.575 | 120mesh | 0.08 | 0.132 |
10mesh | 0.55 | 1.99 | 140mesh | 0.07 | 0.111 |
12mesh | 0.5 | 1.616 | 150mesh | 0.065 | 0.104 |
14mesh | 0.45 | 1.362 | 160mesh | 0.065 | 0.094 |
16mesh | 0.4 | 1.188 | 180mesh | 0.053 | 0.088 |
18mesh | 0.35 | 1.06 | 200mesh | 0.053 | 0.074 |
20mesh | 0.3 | 0.97 | 250mesh | 0.04 | 0.061 |
26mesh | 0.28 | 0.696 | 300mesh | 0.035 | 0.049 |
30mesh | 0.25 | 0.596 | 325mesh | 0.03 | 0.048 |
40mesh | 0.21 | 0.425 | 350mesh | 0.03 | 0.042 |
50mesh | 0.19 | 0.318 | 400mesh | 0.025 | 0.0385 |
Aluminum window screen is woven from aluminum wire or aluminum-magnesium alloy wire.aluminum insect screen is also called magnalium wire screen. Its natural color is silver white. And our Aluminum screens can be coated with epoxy coating to green, silver gray, yellow and blue, or with charcoal coated in black color.
Structural precision, uniform mesh, with good corrosion resistance and strong and durable and so on. Widely used in industrial and construction industry, screening sand, filter, filter liquid and gas. It can also be used for mechanical accessories such as security protection.
Stainless Steel Window Screen can prevent insects, so it is ideal for porch, window and door applications. It also can be applied on the high-temperature areas and humid environment, for the merits of heat-resistance, moister-resistance and anti-corrosion
Stainless steel wire
Stainless steel 304(0Cr18Ni9),316(0Cr17Ni12Mo2),316L(C≤0.030)
The wire is made to the mesh by woven machine
The stainless steel wire was woven into the wire mesh rolls
Stretch the wire mesh , in order to make it smooth
Our company was established in 2009 and it has 5000 m2 production workshop, Hundreds of skilled technicians, Dozens of production and processing lines. We have many years of experience in the wire mesh field.
We have a strict quality inspection system and a professional testing team, we guarantee product quality
24 hours on-line service ,Free samples if stocked, Quality problem we could accept the products return
Competitive price with superior higher quality products,Professional team to solve all your questions
We have professional team to produce the Stainless Steel Window Screen ,before sending the goods, before the delivery the material ,mesh acounts ,wire diameter and other items of the product are tested,we can guarantee the high quality products.
